Mild Steel Unequal Angles
Need a price for this?
Send your sizes and quantity on WhatsApp +971 56 227 5722 or through the quote request form, and you get a figure back with a lead time. Cut to length included, mill test certificates with the material, delivery to all seven emirates.
Mild steel unequal angles have one leg longer than the other. That extra length gives a wider face to bolt to, or more stiffness in the direction that matters, without paying for a heavier equal angle. They are common on lintels, purlin cleats, tower structures and anywhere a flush fixing is needed on one side. Seen Steel supplies unequal angles from 65 x 50 up to 200 x 150, cut to length and delivered to all seven emirates.
Sizes and weights
Standard length is 6 m. Weights are approximate, calculated from the section geometry at 7.85 g/cm³.
| Size (mm) | Thickness (mm) | Approx. kg per metre |
|---|---|---|
| 65 x 50 | 5 / 6 | 4.35 / 5.16 |
| 75 x 50 | 6 / 8 | 5.65 / 7.39 |
| 100 x 65 | 7 / 8 / 10 | 8.77 / 9.94 / 12.3 |
| 100 x 75 | 8 / 10 | 10.6 / 13.0 |
| 125 x 75 | 8 / 10 | 12.2 / 15.0 |
| 150 x 75 | 9 / 10 / 12 | 15.0 / 16.6 / 19.7 |
| 150 x 90 | 10 / 12 | 18.2 / 21.6 |
| 200 x 100 | 10 / 12 / 15 | 23.0 / 27.3 / 33.7 |
| 200 x 150 | 12 / 15 | 31.6 / 39.0 |
To work out any angle yourself: kg per metre = (leg A + leg B − thickness) × thickness × 0.00785, with all dimensions in mm. The real section is slightly heavier because of the root radius, so treat the figure as an estimate and invoice against the mill certificate. The full method is in our steel weight chart.
When to use an unequal angle
- A lintel or support where the long leg carries the load and the short leg bolts to the structure
- Cleats and brackets that need a wider bolting face on one side only
- Members where stiffness is needed in one direction, for the same weight of steel
- Edge and trim details where one leg has to sit flush
Where both directions matter equally, an equal angle is usually the simpler and cheaper option.
Grades and standards
- Dimensions: BS 4848 Part 4, EN 10056-1 or JIS G3192 depending on origin
- Material: EN 10025-2 S235JR or S275JR, ASTM A36, or JIS SS400
- Galvanized: hot dip to EN ISO 1461 on request
Our guide to steel grades sets the grades side by side.
Common applications
- Bracing and cleats in structural steelwork
- Frames for gates, doors, grilles and grating
- Tower, mast and transmission structures
- Edge protection, trims and corner guards
- Machinery bases, brackets and supports
- Racking, shelving and mezzanine framing
Cutting and delivery
We supply 6 m lengths or cut to your list. Deliveries go to workshops and sites across all seven emirates, including Al Quoz, Jebel Ali, Mussafah, Sajaa, Ajman Industrial and Al Hamra. Mill test certificates are supplied with the material.
Buying unequal angle from Seen Steel
Where unequal angle earns its place
Unequal angle is specified when the load runs mainly one way, or when one face has to be wide enough to take a bolt group that would not fit on a square leg. It is also the cheaper answer where an equal angle large enough to give the needed depth would be heavier than the job warrants. If you are choosing between the two, the deciding question is usually which face you are fixing through.
Who buys unequal angle from us
- Structural fabricators working to a consultant drawing that calls out the section
- Trailer and truck body builders using the long leg as a chassis edge
- Shelving and racking makers fixing shelves through the wider face
- Plant and quarry operators replacing worn framing and bracing
Lengths and cutting
Standard supply is 6 metre lengths. Because unequal angle is usually bought for a specific structural purpose rather than kept as general stock, most orders come as a cutting list against a drawing, and that is the way to buy it. Cutting is included rather than charged on top, so there is no reason to take full lengths and cut them yourself.
Where we deliver
Deliveries run to every emirate: Dubai, Abu Dhabi, Sharjah, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain. Longer sections in the heavier sizes are awkward to handle by hand, so let us know what offloading you have before the truck is loaded.
Getting the section right
Write both legs and the thickness every time. A request for "100 x 50 angle" leaves the thickness open, and the weight between a 6 mm and a 10 mm is a long way apart. Where the drawing names a standard, quote it, because the same nominal size rolled to a different standard can differ at the root radius.
Sizes, weights and the full chart
Every standard unequal size with its weight per metre is in our steel angle sizes and weight chart for the UAE, alongside the equal angle range and the formula for calculating any section by hand.
What to send for a quote
- Size and thickness, for example 100 x 75 x 8
- Grade, if specified
- Black or galvanized
- Lengths or cutting list, and quantity
- Delivery location
Frequently asked questions
What is the weight of a 100 x 75 x 8 unequal angle?
About 10.6 kg per metre, so roughly 64 kg for a 6 m length.
How do I specify an unequal angle?
Long leg first, then short leg, then thickness: 150 x 90 x 10.
Is an unequal angle stronger than an equal angle?
In the direction of the long leg, yes, for the same weight. In the other direction it is weaker, so orientation matters.
Do you supply mill test certificates?
Yes, MTCs are issued with the material.
Send your unequal angle requirement through the steel quote request form or on WhatsApp at +971 56 227 5722.
